Premium Welding Cable

Auweld cables are sold in 100m per spool and are available in conductor areas from 10mm² to 185mm². They are strongly recommended for Heavy Duty usage.

Material Features

Conductor
0.2mm stranded plain annealed copper conductors in tightly bonded braids for high conductivity

Sheath
Heavy duty heat, fire, oil resistant PVC, meter marked

Voltage Drop

When total cable length exceeds 15 meters, we recommend using the next larger size cable to minimize voltage drop and maintain adequate welding current.

Features

  • High Conductivity; copper purity >99.9%
  • Outstanding flexibility and conductivity
  • Excellent ozone and weather resistance
  • Strong resistance against oil, chemicals and solvents
  • Flame retardant

Categories: ,

Specifications

PRODUCT NO. NOMINAL CONDUCTOR AREA (mm²) NOMINAL OVERALL DIAMETER (mm) NOMINAL COPPER DIAMETER (mm) NOMINAL THICKNESS OF INSULATION (mm) NO. OF WIRE X WIRE DIAMETER (mm) CONDUCTOR RESISTANCE
Ω/km @ 20°C
260310102 10 8.2 4.7 2.4 322/0.2 1.91
260315162 16 9.3 5.9 2.5 513/0.2 1.21
260320252 25 10.65 7.3 2.6 798/0.2 0.78
260330352 35 11.8 8.5 2.7 1,121/0.2 0.55
260340502 50 13.7 10.2 2.8 1,596/0.2 0.39
260350702 70 15.92 12.1 2.8 2,220/0.2 0.27
260360952 95 18.2 14 3.0 2,997/0.2 0.21
260370122 120 19.10 15.8 3.2 1,702/0.3 0.16
 260380152 150 24.55 17.7 3.4 2,146/0.3 0.13
 260390182 185 26.40 19.4 3.7 1,443/0.4 0.11

DUTY CYCLE (IEC245-82)

  • Continuous 100%
  • Heavy 60%
  • Light industrial 30%
  • Limited input 25%

The typical duty cycles for various welding processes and applications are as follows:
Automatic welding: Up to 100%
Semi-automatic welding: 30% to 85%
Manual welding: 0% to 60%

AMBIENT TEMPERATURE (°C) 20°C 25°C 30°C 35°C 40°C 45°C 50°C 55°C 60°C 65°C
 RATING FACTOR 1.04 1.00 0.96 0.91 0.87 0.82 0.76 0.69 0.64 0.57
